• Low elongation in use: The belts only need a very short take-up stroke distance.
• Superior adhesion: Due to the excellent penetration of rubber between the individual cord filaments.
• Even tension of steel cords: Out of our advance techniques in manufacturing, the steel cords are evenly arranged and carry equal tension during the manufacturing process.
• Good trough-ability: As the belts body has no transverse reinforcement, it is easy to form a deep trough, so the belts can load more materials and prevent the materials from escaping.
| Class Rating | Working Tension (N/mm)n | Cord Dia (mm) | Pitch (mm) | Standard Cover Thickness (mm) | Weight (Kg/m²) | Min Pulley Dia Drive (mm) | Min Pulley Dia Low Tension (mm) | Min Pulley Dia Snub (mm) |
|---|---|---|---|---|---|---|---|---|
|
ST500 |
71.4 |
2.2 |
10 |
5 x 5 |
16.3 |
500 |
400 |
315 |
|
ST630 |
90 |
2.5 |
10 |
5 x 5 |
17.2 |
500 |
400 |
315 |
|
ST800 |
114.2 |
2.9 |
10 |
5 x 5 |
18.3 |
500 |
400 |
315 |
|
ST1000 |
157.1 |
3.6 |
12 |
6 x 6 |
19.2 |
500 |
400 |
315 |
|
ST1250 |
178.6 |
4.0 |
12 |
6 x 6 |
20.5 |
630 |
500 |
400 |
|
ST1600 |
228.6 |
4.6 |
12 |
6 x 6 |
25.5 |
630 |
500 |
400 |
|
ST2000 |
285.6 |
4.6 |
12 |
6 x 6 |
27.9 |
630 |
500 |
400 |
|
ST2500 |
357 |
6.2 |
15 |
8 x 6 |
32.2 |
1000 |
800 |
630 |
|
ST3150 |
450 |
7.1 |
15 |
8 x 6 |
37.4 |
1000 |
800 |
630 |
|
ST4000 |
571.4 |
8.1 |
15 |
8 x 6 |
42.2 |
1250 |
100 |
800 |
|
ST4500 |
642.8 |
8.4 |
15 |
8 x 8 |
45.1 |
1250 |
1000 |
800 |
|
ST5000 |
714.2 |
9.0 |
15 |
8 x 8 |
48.5 |
1500 |
1250 |
800 |
