Applications for Chevron Conveyor Belt
Chevron Conveyor Belt Technical Data
Features
• Slip – Belt is equipped with vertical cleats to withstand material slip
• Properties – Ability to convey materials at an inclination of up to 45°
• Design – Cleat pattern, angle and height to suite all applications
• Properties – Ability to convey materials at an inclination of up to 45°
• Design – Cleat pattern, angle and height to suite all applications
| Type of Material | Example | Max Inclination Angle Height of Cleats 6mm | Max Inclination Angle Height of Cleats 15mm | Max Inclination Angle Height of Cleats 17mm | Max Inclination Angle Height of Cleats 25mm |
|---|---|---|---|---|---|
|
Powdery |
Flour, powder |
15 - 20° |
25° |
28° |
30° |
|
Loose Flowing |
Corn, barley, wheat, rye |
15 - 20° |
20 - 25° |
25-30° |
25-30° |
|
Loose Rolling |
Gravel, stone, ash, soil |
15 - 20° |
25° |
28° |
30° |
|
Sticky |
Wet sand, ash, soil |
20 - 30° |
30 - 35° |
30-35° |
40-45° |
|
Packed |
Boxes, paper, sacks |
30 - 35° |
30 - 35° |
30-35° |
35-40° |
Chevron belt is utilized for conveying loose, bulk or bagged materials at short flight inclined angles
